		Case Style	Control	Sensor Type	Impedance (Ω)	F. Low (MHz)	F. High (MHz)	Input Power (dBm), Min	Input Power (dBm), Max	Dynamic Range (dB), Typ	Measurement Speed (ms)
1	PWR-2.5GHS-75	JL1337_x000D_ _x000D_ _x000D_ _x000D_	USB	CW	75	0.1000	2,500	-30.0000	20	50	30
2	PWR-4GHS	JL1504_x000D_ _x000D_ _x000D_ _x000D_	USB	CW	50	0.0090	4,000	-30.0000	20	50	30
3	PWR-6GHS	JL1504_x000D_ _x000D_ _x000D_ _x000D_	USB	CW	50	1.0000	6,000	-30.0000	20	50	30
4	PWR-6LGHS	JL2169_x000D_ _x000D_ _x000D_ _x000D_	USB	CW	50	50.0000	6,000	-45.0000	10	55	30
5	PWR-6LRMS-RC	JL1941_x000D_ _x000D_ _x000D_ _x000D_	USB & Ethernet	RMS	50	50.0000	6,000	-45.0000	10	55	30
6	PWR-6RMS-RC	JL1941_x000D_ _x000D_ _x000D_ _x000D_	USB & Ethernet	RMS	50	50.0000	6,000	-35.0000	20	55	30
7	PWR-8P-RC	JL2441_x000D_ _x000D_ _x000D_ _x000D_	USB & Ethernet	Peak & Avg.	50	10.0000	8,000	-60.0000	20	80	2
8	PWR-8FS	JL1504_x000D_ _x000D_ _x000D_ _x000D_	USB	CW	50	1.0000	8,000	-30.0000	20	50	10
9	PWR-8GHS	JL1504_x000D_ _x000D_ _x000D_ _x000D_	USB	CW	50	1.0000	8,000	-30.0000	20	50	30
10	PWR-8GHS-RC	JL1941_x000D_ _x000D_ _x000D_ _x000D_	USB & Ethernet	CW	50	1.0000	8,000	-30.0000	20	50	30
