This week I have selected for you 4 Mini-Circuits products for you to discover. We also have a position for a Senior RF Engineer at Mini-Circuits Israel (Kyriat Bialik). Please check it out and do not hesitate to recommend it to your friends.
|
I hope you will enjoy the read and look forward to be of further assistance to you.
|
As always, please feel free to contact us with any questions you may have.
|
|
|
|
|
|
|
|
|
Mini-Circuits will have a strong presence at the 2025 IEEE MTT-S International Microwave Symposium (IMS) in San Francisco from June 15–20, featuring a keynote by CEO Jin Bains and four MicroApps talks by company engineers. Attendees can visit Booth #1351 to explore a wide range of innovative products, including high-frequency amplifiers, GaAs MMICs, micro-ceramic components, RF energy solutions, test equipment, and advanced RF filters. The exhibit will also feature interactive demos and a revamped photo-booth experience. Numerous Mini-Circuits team members and subject matter experts will be available for meetings, which can be scheduled by email.
|
|
|
|
|
|
|
|
|
|
Die MMIC, Medium Power, pHEMT Amplifier
100 kHz to 22 GHz, 50Ω
|
|
Mini-Circuits’ AVA-223MP-DG+ is a wideband, high dynamic range, MMIC amplifier fabricated on a GaAs pHEMT process with high output power and broadband gain. Operating from 100 kHz to 22 GHz, this amplifier features typical +25.9 dBm P1dB, +27.7 dBm PSAT, 3.1 dB NF, and +37.9 dBm OIP3. This device is matched to 50Ω and measures only 3.28 x 1.55 mm.
|
|
|
|
|
|
|
|
Hand-Flex Interconnect, 0.086" center diameter
6.0 GHz
|
|
086-12SMMCR+ Hand-Flex™ coaxial cable is a semi-flexible cable ideal for interconnecting coaxial components and subassemblies in a wide range of systems, including communications, military and aerospace, environmental test chambers and more. The hand-formable cable provides a minimum bend radius of 6 mm to accommodate tight layouts without the need for bending tools, adapters or brackets. SMA-Male and Right-Angle MCX-Male connectors …
|
|
|
|
|
|
|
|
SMT RF Choke
50 MHz - 8.2 GHz, 50Ω
|
|
Mini-Circuits' TCCH-80A+ RF Choke achieves very wide bandwidth from 50 up to 8200 MHz. The RF Choke features 200 mA max DC Current, excellent Insertion Loss and VSWR (1.1:1 typ.), flatness and its 0.15x0.15x0.15" size makes it an ideal solution for rf-choke applications across a very wide frequency range and dense circuit board layouts. These units support a broad range …
|
|
|
|
|
|
|
|
Thin Film SMT Low Pass Filter
DC - 7.3 GHz, 50Ω
|
|
Mini-Circuits’ Surface Mount Thin-Film filters offer low insertion loss and high rejection realized via Thin-Film on Alumina substrate, using a sputtering process that can guarantee an enhanced Q and repeatable performance. Low pass, high pass, and bandpass surface mount thin-film designs can be realized with this technology up to 40 GHz in a small form factor helping customers achieve their …
|
|
|
|
|
|
|
|
SENIOR RF Engineer (MANAGERIAL)
Mini-Circuits Israel #05-2025
Mini-Circuits Israel develops components and test equipment for the commercial market. We are looking for a motivated RF development engineer, to join our RF team. The candidate will design mixed signal units and will be responsible for the full lifecycle of the product – from concept, schematic, layout, testing stages until final production and will work closely also with the global organization.
|
Location: Kiryat Bialik (North Israel)
On-site full-time position
|
- At least 8 years’ experience in RF and microwave design.
- Hands on experience in lineups, schematic and layout design of high frequency mixed signal boards (above 20Ghz – an advantage).
- Experience in RF simulations: 2D (ADS or similar) and 3D (HFSS or CST)
- Experience in RF and microwave testing equipment (VNA, spectrum analyzer, power meters etc).
- Experience in digital HW (microcontrollers and FPGAs) – an advantage.
- Good communication skills, teamwork, and self-learning and managerial skills.
- BSc in Electrical engineering (MSC and advantage).
|
|
|
Want to recomment this job to a friend? Just go to our jobs page and click the Email button.
|
|
|
|
|
|
|
|
Tel: 03-7988118
Mobile: 054-4600801
|
|
|
Tel: 03-6736696
Mobile: 054-2008813
|
|
|
|
Our Engineering Team is here to help you!
|
MCDI, Mini-Circuits Exclusive Representative in Israel, hosts a professional team of Application Engineers with decades of experience. Our Engineers are here to assist with identifying the products that are just right for you, advise on correct setups and solutions. They are just a phone call or an email away and also will be delighted to meet you at your location throughout Israel. You may call them directly by clicking on their picture or visit our support page.
|
|
|
|
|
|
|
|
