RF Components for Automotive Applications
|
Mini-Circuits’ offers a wide range of off-the-shelf RF components capable of meeting the stringent requirements of the AEC-Q200 quality standard. With hundreds of models in stock plus fast, affordable custom designs, industry-leading quality and engineering support, chances are we have a solution for your project requirements.
|
|
|
|
|
|
|
|
Happy Hanukkah from all of us at MCDI!
|
As we celebrate the Festival of Lights, we wish you and your loved ones a joyful Hanukkah filled with light, warmth, and hope. May the glow of the menorah inspire optimism, resilience, and new possibilities, and may the coming days bring success, good health, and continued partnership.
|
Thank you for being part of our journey. We look forward to illuminating new opportunities together in the year ahead.
|
This week I have selected for you 4 Mini-Circuits products for you to discover.
|
I hope you will enjoy the read and look forward to be of further assistance to you.
|
As always, please feel free to contact us with any questions you may have.
|
|
|
|
|
|
|
|
20dB LTCC SMT High Power Directional Coupler
3300 - 4000 MHz, 50Ω
|
|
Mini-Circuits’ HPCJ-20-43+ is an LTCC directional coupler from 3300 to 4000 MHz, supporting a variety of applications. This model provides 0.09 dB typical mainline loss, 20 dB coupling, and 30 dB directivity. It handles up to 50 W RF input power and provides a wide operating temperature range from -55 to +125°C. Housed in a small 0.125” x 0.2” x …
|
|
|
|
|
|
|
|
Cavity Band Pass Filter
16.45 - 17.45 GHz, 50Ω, 2.92mm Female
|
|
Mini-Circuits’ cavity filters are designed by implementing resonant structures with very high Q and are ideal for narrow-band, high-selectivity applications. These designs can provide bandwidths as narrow as 3% with very high selectivity and excellent low noise floor. Low insertion loss combined with excellent power handling makes them well-suited for transmitter and receiver front end. Advanced filter design and construction …
|
|
|
|
|
|
|
|
Absorptive SP4T, Die Switch
DC - 30 GHz, 50Ω
|
|
Mini-Circuits’ M4SWA4-34DR-D+ is a GaAs MMIC SP4T absorptive switch with an internal driver designed for wideband operation from DC to 30 GHz. This switch has fast, nano-second switching across a wide frequency range with exceptional settling time. This model provides excellent isolation, high linearity, and is capable of withstanding +24 dBm RF input power. The M4SWA4-34DR-D+ die is suitable for …
|
|
|
|
|
|
|
|
0.7 to 6 GHz Signal Generator (-60 dBm to +24 dBm)
|
|
Categories: Signal Generators
|
Mini-Circuits’ SSG-R7N6G-RC is a wide-band signal generator operating from 700 to 6000 MHz. With up to +24 dBm typical output power, it is an ideal signal source for characterization of RF and microwave components and systems at high power. Configure CW / single-tone outputs, flexible pulse sequences, AM, FM and Chirp modulations, or automated frequency / power sweep & hop …
|
|
|
|
|
|
JOIN MINI-CIRCUITS ISRAEL
|
|
|
SENIOR RF Engineer (MANAGERIAL)
Mini-Circuits Israel #05-2025
Mini-Circuits Israel develops components and test equipment for the commercial market. We are looking for a motivated RF development engineer, to join our RF team. The candidate will design mixed signal units and will be responsible for the full lifecycle of the product – from concept, schematic, layout, testing stages until final production and will work closely also with the global organization.
|
Location: Kiryat Bialik (North Israel)
On-site full-time position
|
- At least 8 years’ experience in RF and microwave design.
- Hands on experience in lineups, schematic and layout design of high frequency mixed signal boards (above 20Ghz – an advantage).
- Experience in RF simulations: 2D (ADS or similar) and 3D (HFSS or CST)
- Experience in RF and microwave testing equipment (VNA, spectrum analyzer, power meters etc).
- Experience in digital HW (microcontrollers and FPGAs) – an advantage.
- Good communication skills, teamwork, and self-learning and managerial skills.
- BSc in Electrical engineering (MSC and advantage).
|
|
|
Want to recomment this job to a friend? Just go to our jobs page and click the Email button.
|
|
|
|
|
|
|
|
Tel: 03-7988118
Mobile: 054-4600801
|
|
|
Tel: 03-6736696
Mobile: 054-2008813
|
|
|
Tel: 03-5406052
Mobile: 054-4999216
|
|
|
|
Our Engineering Team is here to help you!
|
MCDI, Mini-Circuits Exclusive Representative in Israel, hosts a professional team of Application Engineers with decades of experience. Our Engineers are here to assist with identifying the products that are just right for you, advise on correct setups and solutions. They are just a phone call or an email away and also will be delighted to meet you at your location throughout Israel. You may call them directly by clicking on their picture or visit our support page.
|
|
|
|
|
|
|
